Brand Name : Cheng Wen
Model Number : P2.5-16S
Certification : CE
Place of Origin : Made in China
MOQ : 1pc
Price : $300/pc
Payment Terms : T/T, Western Union, MoneyGram
Supply Ability : 300sqm/month
Delivery Time : 5-8 days
Packaging Details : 6in1 ,8in1 flight case
Module size : 160mm*80mm
Pixel pitch : 2mm
Pixels Density : 160000 dots/m²
Pixel configuration : 1R1G1B
Package mode : SMD2121
Cabinet Size : 480mm*480mm
Specification
Unit Module | Item | Parameter |
Model Number | QF-P2.5-16S | |
Module size | 160mm*80mm | |
Pixel pitch | 2.5mm | |
Pixels Density | 160000dots/m² | |
Pixel configuration | 1R1G1B | |
Package mode | SMD2121 | |
Pixel resolution | 64dots(W)*32 dots(H) | |
Max Power consumption | 22W | |
Drive type | Constant drive | |
Scan mode | 1/16 scan 1/16 | |
Port type | HUB75-A | |
Brightness of white balance | 1600-2000cd/m² | |
Cabinet size | 480mm*480mm |
More Questions
A: DIP-- It means put the bases of DIP packaging lights through PCB, and fill the pin in lamp holders by welding.
SMD-- It means put SMT packing lapms weld on PCB.
A:Compared with DIP Display, SMD display have the advantage of light weight, wide visual angle, good color fidelity, and better color uniformity.For production, SMD is easy to use automatic machine to produce . Save the labor cost and able to large-scale production. In the future , SMD display will have more competitive price. But DIP Display also have the advantage. The waterproof function , the brightness, moisture-proof and UV protection function. Performance of DIP display is better.
A: We guarantee all of our module and spare parts two years.
A: Yes. Please inform us formally before our production .
A: T/T , usually 30% prepayment before production, 70% balance to be paid before delivering,it also change according to total quantity
